STANDEAD WEIGHTS – CYLINDRICAL FOR TESTING OF HIGH CAPACITY WEIGHING MACHINE
Nominal Value: 500kg, 1000kg 2000kg 5000kg
Class: M1/M2/Class 6/ Class 7
Material: Cast Iron, Steel Plated with cast iron
High density and accurate stability in time
It can be used for calibration of load cell, weighbridge, platform scales, truck scales, floor scales, animal scales, counting scales, bench scales and so on. Mainly used for industrial calibration.
Lower cost, custimized shape suitable for each demands. Easy to move.
| OIML | |||||
| Denomination Metric |
Tolerance | ||||
| M1 | M12 | M2 | M23 | M3 | |
| 5000kg | 250000 | 500000 | 800000 | 1600000 | 2500000 |
| 2000kg | 100000 | 200000 | 300000 | 600000 | 1000000 |
| 1000kg | 50000 | 100000 | 160000 | 300000 | 500000 |
| 500kg | 25000 | 50000 | 80000 | 160000 | 250000 |
| 200kg | 10000 | 20000 | 30000 | 60000 | 100000 |
| 100kg | 5000 | 10000 | 16000 | 30000 | 50000 |
| 50kg | 2500 | 5000 | 8000 | 16000 | 25000 |
| ASTM E617-13 | ||
| Denomination Metric |
Tolerance | |
| Class 6 | Class 7 | |
| 5000kg | 500g | 750g |
| 3000kg | 300g | 450g |
| 2000kg | 200g | 300g |
| 1000kg | 100g | 150g |
| 500kg | 50g | 75g |
| 300kg | 30g | 45g |
| 200kg | 20g | 30g |
| 100kg | 10g | 15g |
